DESCRIPTION
Cartridge filter housing is an integral part of the water filtration process, used in the pre filtration and post filtration scheme, it houses cartridge filters which helps in removing small suspended particles from the water. With its unique design and high pressure retention nature these housing show remarkable consistency in water treatment applications.
Technical Specifications:
Materials
Housing Sump / Top Polypropylene
Vent Polypropylene with Stainless Steel Spring and Screw
“O”-ring / Gasket Silicon, FKM, Buna-N, EPDM
Suitable cartridge
Length 20”
Diameter 4.5”
End Connection DOE / ZeroLeak (for 4.5” OD Cartridges only)
Configuration
Housing Size 10”
Diameter Jumbo (for 4.5”)
Connection Type BSP (F) Threaded
Connection Size (Jumbo) 1”, 1.5”
Operating conditions
Maximum operating pressure 0.8 MPa (8.0 bar; 113.7 psid) @ 21°C (69.8°F)
Operating temperature range 4°C ( 39.2°F ) to 70°C ( 158°F )
Flow rates
20” Jumbo upto 8 m3 /hr
